Wear lining attachment systems

Wear lining attachment systems

Our unique fasteners eliminate the need for traditional studs and nuts and improve safety and uptime

Changing out wear liners can be a risky, costly and time consuming exercise, particularly in chutes with limited or no access to external walls. When purchased as part of a liner system our unique fasteners help you overcome these challenges.

Benefits

Improved safety

No hot work situations and less exposure to confined spaces.

Increased uptime

Easy-to-remove fasteners allow short downtime for relining.

Lower costs

Less maintenance and fewer manhours equal more uptime and lower costs.

EzyLock™

Improve safety and uptime with our unique EzyLock™ fastener that enables wear lining change-outs from the easy-to-access wear side only. Simple removal process that eliminates the need for hot works.

  • Single-sided fastener (wear side) for all types of metallic liners
  • High strength tapered bolt head maintains clamping force throughout wear life cycle
  • Head finish flush with wear surface to reduce preferential wear
  • Larger/fewer plates can be used when utilizing SafeFit™ system
  • Removes the need for external scaffolding or access to the outside of the chute

Click here to watch a video about Ezylock attachment system.

EzyLock™
Taper-T™

Our unique Taper-T™ wear side only attachment system eliminates the need for traditional studs and nuts, enabling faster, safer and simpler wear plate change-outs.

  • Single-sided fastener (wear side) for metallic and ceramic liners
  • High strength tapered bolt head ensures liner is safely secured throughout wear life cycle
  • Installed with conventional tooling
  • Larger/fewer plates can be used when utilizing SafeFit™ system
  • Removes the need for external scaffolding or access to the outside of the chute

Click here to watch a video about Taper-T attachment system.

Click here to watch a second video about Taper-T attachment system.

Taper-T™
D-Lock™

D-Lock™ is a unique D-shaped bolt that eliminates the need for studs, is long-lasting and easy to use, resulting in less maintenance and safer operations.

  • Double-sided fastener for up to 50 mm thick metallic plate and 100 mm thick cast liners
  • Direct replacement for studs, kidney bolts and other conventional bolting systems
  • Tapered bolt head ensures liner is safely secured throughout wear life cycle
  • Structural grade bolt allows fewer fasteners to be used
  • Compatible with SafeFit™ handling system enabling larger liners to be safely installed and removed
  • Combine with Remlock™ for ease of removal with no hot works
D-Lock™
RemLock™

No more struggling to remove nuts that, over time, are nearly impossible to get off, and then resorting to cutting them off with an oxy torch. The RemLock™ nut solves this issue and makes bolt or stud removal safer and faster.

  • A unique locknut that replaces traditional nuts
  • Fits all existing studs and bolting systems
  • Separately removable nylon locking feature allows thread locking and easy nut removal
  • Installed with standard tools in the same way as traditional nuts
  • Nylon cap ensures thread corrosion protection
  • No hot works needed to remove corroded bolts and nuts

Click here to watch a video about RemLock attachment system.

RemLock™
XLOK™

Metso XLOK™ is a tough modular liner system and the ultimate choice for situations where equipment can only be accessed from the inside or where a single-sided bolting system provides maintenance savings. XLOK™ delivers consistent liner position on all four sides with no guesswork or measuring to install as the backplate automatically spaces the liners.

XLOK™
