Not sure which mobile crusher or screen to choose?
Try out our new aggregates equipment recommender tool
Nordtrack™ mobile crushers are designed for asphalt recycling, concrete demolition and small scale aggregate production. They are ideal equipment when you work in short-term contracting jobs or are just starting your own operations.
Dependable solution for contracting jobs
Nordtrack™ range of mobile crushing equipment makes it easy to get your asphalt recycling and concrete demolition as well as small-scale aggregate production operations up and running on time and on budget.
With standard, preconfigured products and a worldwide sales and support network, Nordtrack™ is ideal for contractors who need to meet project timelines and capacity quickly.
Easy to select and order
You don't have to be a crushing and screening expert to get started with selecting your Nordtrack™.
The units come in standard configurations for asphalt recycling, separating organic materials and aggregate production.
The choice of options is limited to features that are necessary for concrete demolition and dust suppression, and which add extra usability – so you only pay for the features that you really need.
Check the video
Nordtrack™ J90 mobile jaw crusher
Nordtrack™ mobile crushers technical specifications
Model | Nordtrack™ J90 | Nordtrack™ J127 | Nordtrack™ I908S | Nordtrack™ I908 |
|---|---|---|---|---|
| Crushing unit | Jaw crusher | Jaw crusher | HSI crusher | Impact crusher |
| Feed opening | 890 x 500 mm (35” x 20”) | 1,270 x 735 mm (50” x 29”) | 860 x 650 mm (34” x 25.6”) | 860 x 650 mm (34 x 25.6”) |
| Engine | Tier 3: Volvo D5 162 kW (218 hp) / Tier 4F: Volvo D5 162 kW (218 hp) | Tier 3 LRC: CAT® C9 261 kW (350 hp) / Stage IIIB: CAT® C9.3 CSE 275 kW (375 hp) / Tier 4F / Stage V: CAT® C9.3B 261 kW (350 hp) | Volvo D8 188 kW (252 hp) | Volvo D8 188 kW (252 hp) |
| Weight | 23,900 kg (52,600 lbs) | 56,500 kg (124,600 lbs) | 27 500 kg (60 700 lbs) | 23,600 kg (52,000 lbs) |
| Transport width | 2,500 mm (8’ 2”) | 3,000 mm (9’ 10”) | 2 600 mm (8’ 4”) | 2,500 mm (8’ 2”) |
| Transport height | 3,000 mm (10’) | 3,600 mm (11’ 8.8”) | 3 000 mm (10’) | 3,000 mm (10’) |
| Transport length | 9,300 mm (30’-”) | 15,500 mm (50’ 8”) | 12 800 mm (42’) | 9,300 mm (30’ 7”) |
| Included in basic configuration | Remote controller for the tracks, Water spraying system with pump, Working lights, Crusher deflector plate, Crusher automation | Remote controller for the tracks, Water spraying system with pump, Aluminum dust cover on main conveyor, Working lights, Crusher deflector plate, Side conveyor | Remote controller for tracks, Water spraying system with pump, Working lights, Crusher automation | Remote controller for the tracks, Working lights, Crusher automation |
| Options | Magnet separator, Side conveyor | Magnet separator | Twin pole magnet separator, Side conveyor, Extra controller for other functionalities | Magnet separator, Water spraying system with pump, Side conveyor |
Nordtrack™ mobile crusher models
